The semi-trailer is manufactured using high-quality materials to
ensure a sturdy and durable structure. It is capable of
withstanding heavy loads and various road conditions to ensure safe
transportation of goods. It is designed with an optimized load
capacity and is capable of carrying a large amount of cargo. It has
a well-designed structure that evenly distributes the weight,
reduces the pressure on the vehicle and improves the efficiency of
the load. The semi-trailer is equipped with high-quality braking
system, tires and suspension system to ensure safety during
transportation. It also offers a stable ride and excellent
maneuverability, reducing the risk of accidents. This vehicle is
designed with operator convenience and comfort in mind. It is
equipped with an easy-to-operate unloading system and convenient
entrances and exits, making loading and unloading easier and more
efficient. This semi-trailer can also be used to transport a
variety of goods, including furniture, building materials and other
large items. Its versatility makes it ideal for a variety of
industries.
Type | Semi-Trailer |
Use | Truck Trailer |
Place of Origin | Shandong, China |
Material | Steel |
Size | 12500x2550x3400mm or Customized |
Product name | Fence Cargo Semi Trailer |
Loading capacity | 30-100Ton or customer's optional |
AXle No.&Brand | 3 Axle FUWA Brand |
Function | Transport sand, stone, gravel,animals, etc |
Suspension | Mechanical Suspension |
Leaf Spring | 90(width)mm*13(thickness)mm*10 layer(especial for exporting market) |
King pin | Jost brand 2.0 or 3.5 inch |
Landing Gear | Yahua Brand 28T |
Tire | 12R22.5 Triangle |
Rim | 9.00*22.5 |
Color | Customers Optional |
Support leg | Jost brand two speed |
Main beam | Q345B steel |
Side beam | 16mm channel steel (Material is Q235B steel) |
Bottom Platform | 3mm checquered steel plate |
Side wall | 800mm height (can be customized) |
Brake chamber | Wabco re 6 relay valve; T30/30+T30 spring brake chamber; two units
of 45L air tanks |
Valve | Wabco valve (especial for exporting market) |
Light | LED Light (especial for exporting market) |
Tool box | One piece 1m *0.5m*0.5m ( size can be customized) |
Painting | Complete chassis sand blasting to clean rust, 1 cost of
anticorrosive primer, 2 coats of final paint, color advised by
customer |
Shipping terms | By bulk vessel, RORO, or 40HQ container |






PACKING AND SHIPPING
We find the best shipping solution according to the actual order
size to reduce the transportation cost and save the transportation
cost for customers Common shipping: bulk carrier, ro-ro
ship,container ship, frame ship
(1) Waxing: carry out wax spraying treatment
(2) Packing: stabilized and fixed with steel wire to protect the
trailer during transportation.
(3) Transportation: Reliable logistics services from well-known
freight forwarding providers to make the transportation process
safe and timely.
(4) In 80% of the cases, we can provide customers with 15-20 days
delivery for regular trailers.
(5) We can ship all trucks and trailers and spare parts by all
means of transportation.
(6) For 90% of our cargoes, we will ship by sea, by container or
roll-on/roll-off/bulk/flatbed to all major continents, such as
South America, the Middle East, Africa, Oceania, etc. We can also
ship by road or by road to the neighboring countries of China, such
as Russia, Tajikistan, Kazakhstan and Mongolia.
(7 )For China's neighboring countries, such as Russia, Tajikistan,
Kazakhstan, Mongolia, etc., we can ship by road or railroad
transportation trucks.
(8) For light spare parts for urgent needs, we can ship them by
international courier services, such as DHL, TNT, UPS or Fedex.
