    3 Axles Dry Bulk Cement Trailer Semi Trailer Cement Powder Trailer

    Ask Lasest Price
    Brand Name : Five Continents
    Price : $16000
    Supply Ability : 500 unit/units per month
    Delivery Time : 15working days
    • Product Details
    • Company Profile

    3 Axles Dry Bulk Cement Trailer Semi Trailer Cement Powder Trailer

    3 Axles dry Bulk Cement tanker Semi Trailer for Cement Powder Transportation tank trailer

    Our 3 axle dry bulk cement tanker semi-trailer is a professional transportation tool for cement powder and other bulk materials. The semi-trailer is equipped with an efficient unloading system, which facilitates quick unloading of cement powder. The unloading system can choose different unloading methods, such as pressure unloading or gravity unloading, to meet the requirements of different scenarios. The semi-trailer is constructed with sturdy frame structure and high-strength materials to ensure the solidity and durability of the whole vehicle. Proper support and reinforcement measures ensure the safety and stability of the tank during transportation.

    Type

    Semi-Trailer
    Max Payload30-60t
    Place of OriginShandong, China
    UseTruck Trailer
    MaterialSteel
    Size12000mm*2490mm*3990mm( Exact size depends on the final design)
    Product nameBulk Cement Trailer
    SuspensionMechanical suspension or Air suspension
    Axles No.3 Axles
    Landing GearJOST Brand Two-speed
    Tire12R22.5
    Axle BrandFUWA Brand 13Ton Axle
    King pinJOST 2.00 or 3.5 inch bolt-in king pin
    Brake SystemWABCO Valve
    Leaf Spring90(W)mm×13(Thickness)mm×10(Layer) or 100mm×12mm×12
    Rims8.00-20 /8.5-20/8.8-20/8.5-22.5/9.0-22.5
    Tare weight(Kg)About 11800KGS-13000KGS
    Tank capacity30cbm-60cbm(Volume optional)
    ShapeOptional(v or w shape)
    CompartmentsOne or two compartment
    Tanker Body Material5mm or 6mm/Q235 carbon steel
    End Plate5mm or 6mm/Q235 carbon steel
    EngineWeichai 4105 Engine
    Manhole Cover500mm carbon steel or aluminum alloy manhole
    Bottom Valve3''/ 4” disc valve
    Discharging ValveDiameter is 3 or 4 inch
    Discharging Pipe4” rubber hose, 2 pcs, 6m/each
    Air compressor10 m3,12m3
    Diesel EngineWeichai Huafeng, Tianhe 4102/4105
    Main BeamHeight 500mm, Upper Thickness 14~18mm,Middle Thickness 8~12mm, Down Thickness 16~20mm.Material:Q345 carbon steel
    Rear ladderDismountable
    LightsTurning Light, Side Marker Light, Tail Light
    Voltage24V
    Receptacle7 ways (7 wire harness)
    PaintingComplete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
    ABSOptional
    AccessoriesOne standard tool box

    3 Axles Dry Bulk Cement Trailer Semi Trailer Cement Powder Trailer

    3 Axles Dry Bulk Cement Trailer Semi Trailer Cement Powder Trailer

    3 Axles Dry Bulk Cement Trailer Semi Trailer Cement Powder Trailer

    3 Axles Dry Bulk Cement Trailer Semi Trailer Cement Powder Trailer

    3 Axles Dry Bulk Cement Trailer Semi Trailer Cement Powder Trailer

    3 Axles Dry Bulk Cement Trailer Semi Trailer Cement Powder Trailer

    PACKING AND SHIPPING


    We find the best shipping solution according to the actual order size to reduce the transportation cost and save the transportation cost for customers Common shipping: bulk carrier, ro-ro ship,container ship, frame ship
    (1) Waxing: carry out wax spraying treatment
    (2) Packing: stabilized and fixed with steel wire to protect the trailer during transportation.
    (3) Transportation: Reliable logistics services from well-known freight forwarding providers to make the transportation process safe and timely.
    (4) In 80% of the cases, we can provide customers with 15-20 days delivery for regular trailers.
    (5) We can ship all trucks and trailers and spare parts by all means of transportation.
    (6) For 90% of our cargoes, we will ship by sea, by container or roll-on/roll-off/bulk/flatbed to all major continents, such as South America, the Middle East, Africa, Oceania, etc. We can also ship by road or by road to the neighboring countries of China, such as Russia, Tajikistan, Kazakhstan and Mongolia.
    (7) For China's neighboring countries, such as Russia, Tajikistan, Kazakhstan, Mongolia, etc., we can ship by road or railroad transportation trucks.
    (8) For light spare parts for urgent needs, we can ship them by international courier services, such as DHL, TNT, UPS or Fedex.
