    Enclosed 3 Axle Box Cargo Trailer 80 Ton High Load Capacity High Capacity

    Ask Lasest Price
    Brand Name : Five Continents
    Price : $16000
    Supply Ability : 500 unit/units per month
    Delivery Time : 15working days
    • Product Details
    • Company Profile

    Enclosed 3 Axle Box Cargo Trailer 80 Ton High Load Capacity High Capacity

    High load capacity 3 axle high capacity box cargo trailer

    Box semi-trailers can be used to transport various types of goods such as general cargo, fast moving consumer goods, industrial raw materials, furniture, electronics and other goods. Box semi-trailers usually have convenient loading and unloading characteristics for easy loading and unloading of goods. Equipped with rear and side doors for easy access to the cargo. The box semi-trailer provides a certain degree of protection during the transportation of goods, which can effectively protect the goods from the influence of the external environment. It can prevent the goods from rain, dust, sunlight and other factors, and reduce the damage and loss of goods during transportation.

    TypeSemi-Trailer
    UseTruck Trailer
    Place of OriginShandong, China
    MaterialSteel
    Size13000*2500*2860(mm)
    Product nameVan or Box Semi Trailer
    ColorCustomers Optional
    Landing Gear28T
    King pin2"(50mm)or3.5"(90mm)
    Tare WeightApprox. 6.2 T
    Dimension13000*2500*3550mm
    Max payload80T
    Axle13/16 Ton BPW/FUWA Brand
    Tire12R22.5
    Rim9.00*22.5/8.00-20/8.5-20
    SuspensionMechanical suspension(Germany type or America type) or Air suspension
    Leaf Spring90(width)mm*13(thickness)mm*10 layer(especial for exporting market)
    King pinJost brand 2.0 or 3.5 inch
    Main beamHeight: 500mm, upper plate is 14mm, middle plate is 8mm, down plate is 16mm; Material is Q345B steel
    Side beam16mm channel steel (Material is Q235B steel)
    Bottom Platform3mm checquered steel plate
    Side wall1800mm height (can be customized)
    Brake chamberWabco re 6 relay valve; T30/30+T30 spring brake chamber; two units of 45L air tanks
    ABSOptional
    Twist locksOptional
    ValveWabco valve (especial for exporting market)
    LightLED Light (especial for exporting market)
    Voltage24V
    Receptacle7 ways (7 wire harness)
    Tool boxOne piece 1m *0.5m*0.5m ( size can be customized)
    PaintingComplete chassis sand blasting to clean rust, 1 cost of anticorrosive primer, 2 coats of final paint, color advised by customer
    Shipping termsBy bulk vessel, RORO, or 40HQ container

    Enclosed 3 Axle Box Cargo Trailer 80 Ton High Load Capacity High Capacity

    Enclosed 3 Axle Box Cargo Trailer 80 Ton High Load Capacity High Capacity

    Enclosed 3 Axle Box Cargo Trailer 80 Ton High Load Capacity High Capacity

    Enclosed 3 Axle Box Cargo Trailer 80 Ton High Load Capacity High Capacity

    Enclosed 3 Axle Box Cargo Trailer 80 Ton High Load Capacity High Capacity

    PACKING AND SHIPPING

    We find the best shipping solution according to the actual order size to reduce the transportation cost and save the transportation cost for customers Common shipping: bulk carrier, ro-ro ship,container ship, frame ship
    (1) Waxing: carry out wax spraying treatment
    (2) Packing: stabilized and fixed with steel wire to protect the trailer during transportation.
    (3) Transportation: Reliable logistics services from well-known freight forwarding providers to make the transportation process safe and timely.
    (4) In 80% of the cases, we can provide customers with 15-20 days delivery for regular trailers.
    (5) We can ship all trucks and trailers and spare parts by all means of transportation.
    (6) For 90% of our cargoes, we will ship by sea, by container or roll-on/roll-off/bulk/flatbed to all major continents, such as South America, the Middle East, Africa, Oceania, etc. We can also ship by road or by road to the neighboring countries of China, such as Russia, Tajikistan, Kazakhstan and Mongolia.
    (7 )For China's neighboring countries, such as Russia, Tajikistan, Kazakhstan, Mongolia, etc., we can ship by road or railroad transportation trucks.
    (8) For light spare parts for urgent needs, we can ship them by international courier services, such as DHL, TNT, UPS or Fedex.
