    2 3 4 Axle 40FT Container Lowbed Trailer Semi Trailers Car

    Ask Lasest Price
    Brand Name : Five Continents
    Supply Ability : 500 units per month
    Delivery Time : 15 working days
    Price : $13000
    • Product Details
    • Company Profile

    2 3 4 Axle 40FT Container Lowbed Trailer Semi Trailers Car

    2/3/4 axle 40FT Containers lowbed semi trailer

    The low-bed semi-trailer is a versatile vehicle suitable for transporting heavy equipment and oversized cargo. It features a low-profile design and sturdy structure for excellent stability and load-carrying capacity. It is equipped with an advanced suspension system and secure tie-down points to ensure safe and secure transportation of machinery, construction materials and other large items. The trailer has an adjustable platform height and extended length to accommodate various cargo sizes and loading requirements. Efficient and flexible, the vehicle is designed to meet the needs of different industries and provide optimum performance.

    Trailer Model3 Axle low bed Semi Trailer
    Total size13000*3000*1650mm
    Working size(LxWxH)9000*3000*1250mm
    Curb Weight(KG)9,000
    Loading Weight(KG)60 ton common good or 40ton vehicles or machinery with wheels or tracks(concentrated stress on the trailer)
    Axle3*13 ton Fuwa axle
    Wheelbase(mm)8580+1310+1310
    Suspension systemMechanical Leaf Spring Suspension
    Leaf Spring90(W)mm*16(Thick)mm*10 Layer
    10/10/10 leaf spring suspension
    The Main BeamQ345B carbon steel,the height of the beam is 500 mm, upper plate is 16mm,down plate is 18mm, middle plate is 10 mm.
    Side Beam Q23520# channel steel
    Platform plate3mm Diamond plate
    Tire Type and quantity11.00R20 12units
    LadderWith Ladder
    Traction Pin2" or 3.5", Jost brand
    Spare Wheel Bracket2 pieces
    Tool Box1 Standard
    Landing Gear28Ton standard 2 speeds, Yahua brand
    Brake systemWABCO RE6 relay valve ;T30/30 spring brake chamber;
    40L air tanks
    Dual Line braking system
    (Steel tube line for low temperature)
    Brake air chamberSix double chamber
    Electrical system1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)
    Tail lamp with turn signal, brake light & reflector, side lamp etc.
    One set 6-core standard Cable.
    PaintingComplete Chassis sand blasting to clean rust, 1 coat of anti-rust prime,2 coats of final paint
    ShippingShipped by bulk cargo ship, Roll-roll ship or in container

    2 3 4 Axle 40FT Container Lowbed Trailer Semi Trailers Car

    2 3 4 Axle 40FT Container Lowbed Trailer Semi Trailers Car

    2 3 4 Axle 40FT Container Lowbed Trailer Semi Trailers Car

    2 3 4 Axle 40FT Container Lowbed Trailer Semi Trailers Car

    2 3 4 Axle 40FT Container Lowbed Trailer Semi Trailers Car

    PACKING AND SHIPPING

    We find the best shipping solution according to the actual order size to reduce the transportation cost and save the transportation cost for customers Common shipping: bulk carrier, ro-ro ship,container ship, frame ship
    (1) Waxing: carry out wax spraying treatment
    (2) Packing: stabilized and fixed with steel wire to protect the trailer during transportation.
    (3) Transportation: Reliable logistics services from well-known freight forwarding providers to make the transportation process safe and timely.
    (4) In 80% of the cases, we can provide customers with 15-20 days delivery for regular trailers.
    (5) We can ship all trucks and trailers and spare parts by all means of transportation.
    (6) For 90% of our cargoes, we will ship by sea, by container or roll-on/roll-off/bulk/flatbed to all major continents, such as South America, the Middle East, Africa, Oceania, etc. We can also ship by road or by road to the neighboring countries of China, such as Russia, Tajikistan, Kazakhstan and Mongolia.
    (7) For China's neighboring countries, such as Russia, Tajikistan, Kazakhstan, Mongolia, etc., we can ship by road or railroad transportation trucks.
    (8) For light spare parts for urgent needs, we can ship them by international courier services, such as DHL, TNT, UPS or Fedex.
